Characteristic:

• Push-in interface, very suitable for quick plug-in and use, convenient and fast;
• Excellent broadband performance and low reflectivity, stable performance;
• High Quality with 30 days 100% Money back;
• From the OEM Original Factory, same quality with much better price.

Main application:

• CaracterAerospace and Defense: Hand-held field Device and Instrumentation
• Technology: Instrumentation
• Commercial Vehicle: Bluetooth and GPS
• Telecommunications: Wireless Base Stations, Cellular Mobile System
• Data/Communications: Wifi, WiMAX
• Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking Systemísticas Elétricas

Electrical Performance：

• Impedance：50 ohm
• Frequency Range: 0~6 GHz
• VSWR: Straight type ≦ 1.3max / R/A type ≦ 1.5max
• Dielectric Withstanding Voltage: 1000 V RMS
• Working Voltage: 335V RMS
• Center Contact Resistance: ≦ 5.0 mΩ  (Milliohms max.)
• Outer Contact Resistance: ≦ 1.0 mΩ  (Milliohms max.)
• Insulation Resistance: ≧ 1000mΩ (Megohms min.)

Mechanical Performance：

• Coupling: Push-in
• Contact Retention: 15 lbs min.
• Coupling nut torque:4lbs. min.
• Durability(mating) : ≧ 500 cycles (For Beryllium Copper Contact)

Environmental Performance：

• Temprature Range: -65°C ~ +155°C
• Vibration: MIL-STD-202 Method204
• Corrosion resistance: MIL-STD-202 Method 101

Material:

• Main body: Brass Au: 1u
• Center needle: Phosphor Au: 3u
• Insulator: TEFLON White

Cooperative factory real shot:
